The points created by AutoCAD Civil 3D are chosen Coordinate Geometry (COGO) points, which are very unlike from AutoCAD betoken nodes. COGO points, in improver to coordinate data, have a variety of properties associated with them, including point number, point proper noun, raw (field) description, and total (expanded) clarification. COGO points can be stored in a projection exterior a drawing and referenced by multiple users.
Even so, AutoCAD Civil 3D doesn't include a built-in tool to convert points represented equally AutoCAD text into COGO points. So, the below steps guides you how to achieve that goal.
Create a new empty surface by right-clicking on Surfaces in Prospector as shown below. If the Prospector palette is not showing, click on the two red boxes as shown in the screenshot below so that they are highlighted.
Select the surface from Prospector to show the contextual ribbon.
On the contextual ribbon, click on 'Movement Text to Elevation' and select the text objects. This will make the Z coordinate for the text equal to the text content. If you are using the 'UK English language' version of Ceremonious 3D the command volition exist 'Movement Text to Level'.
Add the text points to the surface from Prospector as beneath. The points volition take the elevation from the Z coordinate of the text and its position will be the insertion point of the text (the point where the square grip appears when you lot select the text in AutoCAD).
Go to Surface Properties and select a way that shows the points. Otherwise, the choice 'Points' will non be bachelor in the next step.
Select the surface and, on the contextual ribbon, click on 'Extract Objects'. That will insert AutoCAD points in the drawing from the surface.
Modify your point settings then you don't have to striking enter for a description or proper name afterward each bespeak is created.
Finally, from the start drop-down menu in the previous window, convert the AutoCAD points to COGO Points. The COGO points will be visible in the cartoon and listed in Prospector nether Points. They will also be included in the _All Points group.
Nosotros hope you found this tip useful.
